Description

Ubiquiti EdgeRouter 12 ( ER‑12‑U)

←
Get Your Custom Quote!

The EdgeRouter 12 is a robust, fanless wired router tailored for advanced network environments. It offers up to ten Gigabit RJ45 ports, two SFP fiber uplink ports, and flexible passive PoE input and passthrough. Powered by a quad-core MIPS64 CPU with 1 GB DDR3 RAM, it delivers enterprise-level routing performance through EdgeOS or UISP, featuring VLANs, VPN, firewall, NAT, and deep packet inspection.

SPECIFICATIONS

• Ethernet Ports: 10 × Gigabit RJ45

• SFP Ports: 2 × Gigabit SFP (fiber)

• Console Port: 1 × RJ45 serial

• PoE Support:

  • Port 0: Passive PoE input

  • Port 9: Passive PoE passthrough (up to 20W)

• Processor: Quad-core 1 GHz

• Memory: 1 GB DDR3 RAM

• Storage: 4 GB eMMC flash

• Max Performance:

  • 3.4 million packets per second

  • Up to 6.8 Gbps throughput

• Power Supply: 24V, 1A adapter included

• Max Power Usage: 20W (excluding PoE output)

• Cooling: Fanless (silent operation)

• Enclosure: Metal

• Mounting: Wall or rack mountable

• Dimensions: 268.1 × 136.5 × 31.1 mm

• Weight: Approx. 700 grams

• Software Features:

  • EdgeOS / UISP

  • VLAN, QoS, Firewall, NAT

  • VPN: IPsec, OpenVPN, L2TP, PPTP

  • Routing: Static, OSPF, BGP

  • Deep Packet Inspection (DPI)
