Ubiquiti UniFi Switch Ultra 60W (USW-Ultra-60W)

←
Get Your Custom Quote!

The Ubiquiti UniFi Switch Ultra 60W (USW-Ultra-60W) is a compact managed switch offering high-performance connectivity with PoE++ support on RJ45 ports, ideal for powering devices like UniFi access points and cameras with efficient management capabilities.

SPECIFICATIONS

• Model: USW-Ultra-60W
• Dimensions: 213 x 109 x 31 mm (8.39 x 4.29 x 1.22″)
• Weight: 1.6 kg (3.53 lb)
• Enclosure Material: Metal
• Networking Interfaces:
  • (4) 10G SFP+ ports
  • (4) 1G RJ45 ports with PoE++ (up to 60W per port)
• PoE Budget: 60W
• Power Input: 100–240V AC, 1.5A, 50/60 Hz
• Power Consumption: Max 90W
• Operating Temperature: -5 to 45°C (23 to 113°F)
• Operating Humidity: 5 to 95% non-condensing
• Certifications: CE, FCC, IC

FEATURES

• PoE++ Support on 4 RJ45 Ports
• 4 x 10G SFP+ Ports for high-speed uplinks
• Compact and Rugged Metal Enclosure
• Fanless Design for silent operation
• Managed via UniFi Network Controller for easy network configuration
• Advanced Switching Features:
  • VLANs, Link Aggregation, Spanning Tree Protocol
  • QoS and Traffic Prioritization

MANAGEMENT REQUIREMENTS

• UniFi Network Version 7.0 and later
• Managed via UniFi Network Controller (local or cloud hosted)
