Ubiquiti UniFi Switch Pro Max 48 (USW-Pro-Max-48)

←
Get Your Custom Quote!

The Ubiquiti UniFi Switch Pro Max 48 (USW-Pro-Max-48) is a high-performance Layer 3 switch designed for enterprise networks. It features 48 multi-gigabit RJ45 ports and 4 high-speed 10G SFP+ uplinks, delivering exceptional performance and scalability for large-scale deployments.

SPECIFICATIONS

• Model: USW-Pro-Max-48
• Dimensions: 442 x 325 x 44 mm (17.4 x 12.8 x 1.7″)
• Weight: 4.8 kg (10.6 lb) without mounting brackets; 4.9 kg (10.8 lb) with mounting brackets
• Enclosure Material: SGCC steel
• Networking Interfaces:
  • (32) 1G RJ45 Ports
  • (16) 1/2.5G RJ45 Ports
  • (4) 10G SFP+ Uplink Ports
• Power Input: 100–240V AC, 50/60Hz
• Max Power Consumption: 100W
• Switching Capacity: 224 Gbps
• Forwarding Rate: 166.656 Mpps
• Cooling: Active cooling (variable-speed fans)
• Operating Temperature: -5 to 40°C (23 to 104°F)
• Operating Humidity: 10 to 90% non-condensing
• Certifications: CE, FCC, IC

FEATURES

• 48 x Multi-Gigabit RJ45 Ports:
  • (32) 1G Ports
  • (16) 1/2.5G Ports
• 4 x 10G SFP+ Uplinks for ultra-fast aggregation and fiber connectivity
• Layer 3 Routing Capabilities: Static routing, inter-VLAN routing, DHCP server and relay
• Advanced Switching Features:
  • VLANs, Link Aggregation, Spanning Tree
  • IGMP Snooping, QoS, DHCP Snooping
  • ACLs and Broadcast Storm Control
• Touchscreen Display for quick diagnostics and port status
• Managed via UniFi Network Controller for seamless network integration

MANAGEMENT REQUIREMENTS

• UniFi Network Version 8.0.24 or later
• Managed via UniFi Network Controller (cloud or on-premise)
