Description
Ubiquiti UISP Fiber XG UISP-Fiber-XG
The Ubiquiti UISP Fiber XG is an XG-PON optical network unit designed for high-speed fiber customer-premises deployments. It delivers up to 10 Gbps downstream and 2.5 Gbps upstream over single-mode fiber distances up to 20 km, with an SC/APC PON port, 2.5 GbE RJ45 LAN port, USB-C or 24V passive PoE power, and UISP-based management for ISP fiber broadband installations.
Specifications:
- Model: Ubiquiti UISP Fiber XG UISP-Fiber-XG
- Device Type: XG-PON Optical Network Unit / Fiber CPE
- Ethernet Ports: 1 × SC/APC ITU-T G.987 XG-PON WAN port, 1 × 100/1000/2500 MbE RJ45 LAN port
- CPU: Not specified
- RAM: 256 MB DDR
- Storage: 32 MB NOR flash
- Operating System: UISP Fiber ONU firmware
- Routing: XG-PON ONU operation with 10 Gbps downstream, 2.5 Gbps upstream, 20 km physical fiber reach, 1270 nm TX wavelength, 1577 nm RX wavelength, and bridge/router mode support
- Management: UISP application management, Ethernet status LEDs, PON signal LEDs, and factory reset button
- Power: USB-C 5V DC / 3A or 24V passive PoE; maximum power consumption 6W
- Dimensions: 100 × 100 × 27 mm
- Use Case: XG-PON fiber customer premises, ISP subscriber connections, FTTH deployments, business fiber service, residential fiber internet, UISP Fiber OLT XGS networks, and high-speed ONU/CPE installations.
