Ubiquiti EdgePower 54V 72W Power Supply (EP-54V-72W)

←
Get Your Custom Quote!

The EP-54V-72W is a compact, rack-mountable 54V DC power supply with integrated battery backup capabilities. Designed for WISP (Wireless Internet Service Provider) deployments, it offers dual passive PoE outputs and supports remote management via UISP (formerly UNMS). This unit ensures reliable power delivery and provides automatic alerts in the event of power outages, making it ideal for small site installations.

SPECIFICATIONS

• Input Voltage: 100–240V AC, 50/60Hz (Universal Input)

• Output Voltage: 54V DC

• Power Output: 72W

• Output Current: 1.33A

• Networking Interfaces: (2) 10/100 Mbps RJ45 Ports

• PoE Output: (2) 54V DC Passive PoE (Pins 4, 5+; 7, 😎

• DC Output: 54V, 1.3A

• Battery Input: 12V DC Lead Acid Battery (Battery not included)

• Power Consumption: System: 2W; Output: 72W

• Dimensions: 192 x 43.7 x 115 mm (7.56 x 1.72 x 4.53 in)

• Weight: 650 g (1.43 lb)

• Operating Temperature: 0°C to 40°C (32°F to 104°F)

• Operating Humidity: 10% to 90% Non-condensing
