Access Button (UA-Button)

The UniFi Access Button (UA-Button) is a push-to-exit button designed for use with UniFi Access Hubs, providing a simple and reliable way to unlock doors when exiting a secured area . It features a durable polycarbonate enclosure and includes interchangeable black and white faceplates for aesthetic flexibility . Built for indoor use, the button is rated for over 1,000,000 mechanical clicks, ensuring long-term reliability in high-traffic environments .

Specifications:

• Model: UniFi Access Button (UA-Button)

• Device Type: Push-to-Exit Access Button

• Function: Provides a secure and reliable method for requesting egress from a secured area via a UniFi Access Hub

• Dimensions: 137 x 88 x 38.1 mm (5.4 x 3.5 x 1.5″)

• Weight: 180 g (6.3 oz)

• Enclosure Material: Polycarbonate with metal (SGCC steel) mounting

• Color: Black/white (interchangeable faceplates included)

• Contact Type: (1) Normally open

• Contact Rating: 30V DC, 2A

• Mechanical Life: 1,000,000 clicks

• Power Method: UniFi Access Hubs

• Placement: Indoor only

• Operating Temperature: 0 to 40° C (32 to 104° F)

• Storage Temperature: -40 to 70° C (-40 to 158° F)

• Operating Humidity: 5 to 90% noncondensing

• Use Case: Secure exit management for offices, residential buildings, and commercial facilities

• Security Features: UL 294 Level I certified (Destructive attack, Line security, Endurance, Standby power), NDAA compliant

• Management: Integrated with UniFi Access system; compatible with UA-G2-SK, UA-G2-SK-Pro, UA-Hub, EAH-8, and UA-Ultra

• Design: Compact, durable surface-mount design with interchangeable black and white faceplates

• Compatibility: Designed for UniFi Access Hubs and the UniFi Access ecosystem
